NF-Xy All-Electric Pallet Truck V2
- EPS electronic steering, all-steel housing, imported accessories
- High-quality drive system, drive damping technology
- Automatic deceleration of steering, reverse braking, safety and efficiency
Description
- EPS electronic steering, all-steel housing, imported accessories
- High-quality drive system, drive damping technology
- Automatic deceleration of steering, reverse braking, safety and efficiency
| Feature | Value (Metric) | Value (Imperial) |
| Load Capacity | 2500kg | 5512 lbs |
| Load Center | 600mm | 23.62″ |
| Wheelbase | 1555mm | 61.22″ |
| Self Weight (with battery) | 828kg | 1825 lbs |
| Tyre Type | Polyurethane wheels | Polyurethane wheels |
| Drive Wheel Size (Diameter*Width) | Φ248*78mm | Φ9.76*3.07″ |
| Front Wheel Size (Diameter*Width) | Φ80*80mm | Φ3.15*3.15″ |
| Balance Wheel Size (Diameter*Width) | Φ125*50mm | Φ4.92*1.97″ |
| Wheels Number (x-Driven) | 1x+2/4 | 1x+2/4 |
| Lifting Height | 200mm | 7.87″ |
| Fork Height, Lowered | 85mm | 3.35″ |
| Overall Length (stand up/down) | 1990/2380mm | 78.35/93.70″ |
| Overall Width | 860mm | 33.86″ |
| Fork Size | 180/55/1200mm | 7.09/2.17/47.24″ |
| Outer Width of Fork | 550/680mm | 21.65/26.77″ |
| Fork Height, Lowered (Min/Tip) | 30mm | 1.18″ |
| Turning Radius (Pedal up) | 1850mm | 72.83″ |
| Travel Speed (Laden/No Load) | 4/5 km/h | 4/5 km/h |
| Lifting Speed (No Load) | 50mm/s | 1.97″/s |
| Lifting Speed (Laden) | 40mm/s | 1.57″/s |
| Max. Climbing Ability (Laden/No Load) | 5/7% | 5/7% |
| Service Brake | Electromagnetic brake | Electromagnetic brake |
| Drive Motor Rating | AC 1.5kW | AC 1.5kW |
| Lifting Motor Rating | DC 2.2kW | DC 2.2kW |
| Battery Voltage/Rated Capacity | 24V/210Ah | 24V/210Ah |
