NF-Jl All-Electric Truck
- Lithium upgrade, removable lithium battery/ 6 seconds easy battery replacement
- Powerful load-bearing, forged integral forks that refuse to be welded for durability
- Powerful operating handle for simple and easy operation and real-time control
Description
- Lithium upgrade, removable lithium battery/ 6 seconds easy battery replacement
- Powerful load-bearing, forged integral forks that refuse to be welded for durability
- Powerful operating handle for simple and easy operation and real-time control
| Feature | Value (Metric) | Value (Imperial) |
| Model | CBD15 / CBD20 | CBD15 / CBD20 |
| Load Capacity | 1.5 T / 2.0 T | 3307 lbs / 4409 lbs |
| Load Centre | 600mm | 23.62″ |
| Service Weight (without battery) | 120kg / 146kg | 265 lbs / 322 lbs |
| Wheel material | PU | PU |
| Driving wheel size | Φ210x70mm | Φ8.27×2.76″ |
| Balance wheel size | Φ80x60mm | Φ3.15×2.36″ |
| Lifting Height | 200mm | 7.87″ |
| Handle height | 740/1160mm | 29.13/45.67″ |
| Lowered fork height | 85mm | 3.35″ |
| Overall Length | 1603mm | 63.11″ |
| Fork Width | 550/685mm | 21.65/26.97″ |
| Fork Size | 50/150/1150mm | 1.97/5.91/45.28″ |
| Turning Radius | 1398mm | 55.04″ |
| Driving Speed, load/unload | 4.2/4.5 | 4.2/4.5 |
| Maximum gradeability load/unload | 5/10 | 5/10 |
| Brake | Electronic brakes | Electronic brakes |
| Drive Motor | 0.75 | 0.75 |
| Lift Motor | 0.8 | 0.8 |
| Battery voltage/rate capacity | 24V/20ah | 24V/20ah |
